Offers Bresle Patches For Bresle Test Kit. The Bresle Test Patches to TestFor Chloride and Soluble Salt Surface Contaminants on Blasted Surfaces InCompliance With ISO 8502-6 and ISO 8502-9.

Easy To Use, Pour 10mls Of Distilled Water Into The Beaker And Determine The Conductivity UsingThe Conductivity Meter. Take A Bresle Patch and Apply To the Test Surface. Fill The Syringe With2.5mls Of Test Water And Insert Through The Adhesive Foam Into The Test Chamber. Inject TheContents, Then Extract Back Into The Syringe. Repeat Ten Cycles Of Injecting And Extracting ThenTransfer The Test Water Back Into The Beaker. Measure The Test Water With The Conductivity MeterAnd Deduct The Initial Conductivity Reading From The Result. Test Results Are Based On Expression OfResults Are Based On Section 7 Of ISO 8502-9 And Nace SP0508 Specification. Multiply The ReadingsBy 0.1 To Give The Quantity Of Salts In mg/Cm² Also Known As Ppm, Or By 1 For The Quantity Of SaltsMg/M². Multiply mg/m2 Reading By 0.60 To Obtain the Concentration of Chloride Level In mg/m2.Multiply mg /Cm2 Reading by 0.06 to Obtain the Concentration of Chloride Level in mg /Cm2.

The Maximum Permissible Surface Density Of Salts On The Steel Surface Prior To Surface TreatmentDepends On The Type Of Paint To Be Applied And What The Finished Material Or Product Is To BeUsed For. Surface Treatment Specifications Must, Therefore, State The Highest Permissible SurfaceDensity Of Salts For Each Particular Application.
